Evolution R255SMS-DB+ Sliding Miter Saw Spare Parts (Base and Rails)

Latest Model

Find and purchase any part for any Evolution power tool. If you can't find the part you need, then give our friendly, expert customer care team based in Davenport IA, a quick call on 866 EVO-TOOL, toll free. They will find the part and create the order for you, with FREE delivery.

Evolution R255SMS-DB+ Spare Parts (Base and Rails)

Evolution R255SMS-DB+ Sliding Miter Saw Spare Parts (Base and Rails)

Parts List:

A1 - Table Extension x1 (# 048-0301)

$10.99

Only 11 left

A2 - Table Extension x1 (# F-SFCS-M6-16-ST-BO)

$10.99

In Stock

A3 - Foot x1 (# 048-0105)

$2.99

In Stock

A5 - Locking Nut M10 x1 (# F-NNIF-M10-ST-BO)

$10.99

In Stock

A8 - Mitre Detent Handle x1 (# 048-0302)

$5.99

In Stock

A9 - Locking Nut M6 x1 (# F-NNIF-M6-ST-BO)

$10.99

In Stock

A10 - Spring Mitre Handle x1 (# 053-0251)

$2.99

Out of Stock

A11 - Miter Handle Screw x1 (# F-HB-M6-45-ST-BO)

$10.99

Out of Stock

A12 - Base (P) x1 (# 053-0325)

$74.99

Out of Stock

A13 - Grommet 10mm x1 (# 048-0101)

$2.99

Out of Stock

A14 - Hex Key x1 (# 053-0279)

$4.99

Only 1 left

A15 - Mitre Locking Knob x1 (# 048-0109)

$2.99

In Stock

A17 - Push Rod Spring x1 (# 048-0219)

$2.99

In Stock

A18 - Push Rod x1 (# 048-0303)

$2.99

In Stock

A19 - Table x1 (# 053-0150)

$76.99

Out of Stock

A20 - Table Marker x1 (# 048-0115)

$2.99

In Stock

A21 - Pozi pan head screw M5x10 w/ Washer x1 (# F-SFPX-M5-10-ST-BO)

$10.99

Out of Stock

A22 - Hex Bolt M10x35 x1 (# F-HSS-M10-35-ST-BO)

$10.99

Out of Stock

A23 - Kerf Plate x1 (# 053-0151)

$9.99

In Stock

A24 - Socket cap screw M6x28 x1 (# F-SHCS-M6-28-ST-BO)

$10.99

Out of Stock

A25 - Nut M6 x1 (# F-NSF-M6-ST-BO)

$53.99

In Stock

A26 - Chip Deflector x1 (# 053-0260)

$15.99

Only 19 left

A27 - Pozi pan head screw M5x20 x1 (# F-SPHPZ-M5-20-ST-BO)

$10.99

In Stock

A28 - Bevel Marker - P x1 (# 053-0162)

$2.99

Out of Stock

A29 - Bevel Marker Right - P x1 (# 053-0163)

$2.99

Out of Stock

A30 - Angle Limit Pin x1 (# 053-0161)

$4.99

Out of Stock

A32 - Lock Down Pin Knob x1 (# 053-0282)

$2.99

Out of Stock

A34 - Bevel Connect Bolt x1 (# 053-0252)

$5.99

Out of Stock

A35 - Washer Î¦13Xï†24X2.5 x1 (# 053-0312)

$2.99

Out of Stock

A36 - Locking Nut M12 x1 (# F-NNIF-M12-ST-BO)

$10.99

Out of Stock

B1 - Fence (P) x1 (# 053-0152)

$42.99

Only 19 left

B2 - Lock Screw x1 (# 053-0277)

$2.99

Only 6 left

B3 - Sliding Fence Lock Screw x1 (# 053-0289)

$2.99

Out of Stock

B5 - Sliding Fence P-R x1 (# 053-0258)

$15.99

In Stock

B6 - Sliding Fence P-L x1 (# 053-0253)

$15.99

In Stock

C1 - "Pozi pan head screw M5x10" x1 (# F-SPHPZ-M5-10-ST-BO)

$10.99

In Stock

C2 - Bevel Cover Plate-P x1 (# 053-0157)

$4.99

Out of Stock

C3 - Rubber Stop x1 (# 030-0152)

$2.99

Out of Stock

C4 - Shaft Seal Ring Felt x1 (# 053-0263)

$2.99

Out of Stock

C5 - Linear Bearing Lm25Uu x1 (# 048-0162)

$15.99

Out of Stock

C6 - Angle Block x1 (# 053-0283)

$3.99

Out of Stock

C7 - Nut M6 x1 (# F-NSF-M6-ST-BO)

$53.99

In Stock

C8 - Socket set screw M6x20 x1 (# F-SSCFP-M6-20-ST-BO)

$10.99

In Stock

C9 - Socket set screw M6x12 x1 (# F-SSCFP-M6-12-ST-BO)

$10.99

Out of Stock

C10 - Bevel Angle Sticker Plus x1 (# 053-0311)

$10.99

Out of Stock

C12 - O-Ring x1 (# 053-0318)

$2.99

Out of Stock

C13 - 33.9 Pin x1 (# 048-0168)

$3.99

Only 20 left

C14 - Combination Screw x1 (# 053-0316)

$2.99

Out of Stock

C15 - Spacer x1 (# 053-0323)

$2.99

Out of Stock

C16 - Bevel Pivot - P x1 (# 053-0156)

$68.99

Out of Stock

C17 - Spring Mitre Handle x1 (# 053-0251)

$2.99

Out of Stock

C18 - Sliding Bar Lock Scew x1 (# 048-0165)

$2.99

In Stock

C19 - Washer Î¦10.5Xï†20X2 x1 (# 053-0317)

$2.99

Out of Stock

C20 - Bevel Lock Lever x1 (# 053-0165)

$7.99

Only 1 left

C21 - Pozi pan head screw M5x16 x1 (# F-SPHPZ-M5-16-ST-BO)

$10.99

In Stock

C23 - Pozi pan head tapping screw ST4x16 x1 (# F-TFPX-4-16-ST-BO)

$13.99

In Stock

C24 - Handle Front Black - P x1 (# 053-0204-2)

$12.99

Out of Stock

C25 - Handle Rear Black -P x1 (# 053-0204-1)

$12.99

Out of Stock

C26 - Cable Strain x1 (# 053-0293)

$2.99

Out of Stock

C27 - Cable Tidy x1 (# 048-0154)

$2.99

In Stock

C28 - Socket Head Self Tapping Screw St4.8 X 20 x1 (# 053-0285)

$2.99

Out of Stock

C37 - Sliding Bar-P x1 (# 053-0173)

$38.99

Out of Stock

C301 - Flat Pack Lock Mechanism Assembly x1 (# 053-0058)

$7.99

Out of Stock

K306 - Top Clamp Assembly Plus x1 (# 053-0054)

$10.99

In Stock

Cant find what you are looking for? Contact Us Give us a call on: +1 (866) EVO-TOOL
