Evolution RAGE4: Multi-Material Cutting Chop Saw With 7-1/4 in. Blade

Buy Now

Evolution RAGE4: Multi-Material Cutting Chop Saw With 7-1/4 in. Blade

SKU: RAGE4

  • Multi-Material cutting technology.
  • Cuts mild steel with ready-to-weld, clean & square cold-cuts.
  • Accurate & durable vise portability with 0˚ - 45˚ miter detents.
  • Compact, portable, high-quality construction.
  • Read more

3 Year Warranty

45-Day Satisfaction Guarantee

Earn 378 EVO Points with purchase

$189.00
Pay-In-4: $47.25 over 4 months

Frequently Bought Together

Compatible with:

Description

The Evolution RAGE4 is a 7-1/4" Chop Saw (185mm) designed exclusively for Electricians and Plumbers. Producing fast, ultra-clean cuts through armored cable, Unistrut and cable tray, as well as conduit, chrome, copper & plastic pipe, plus plastic hose. Easier to use than a hacksaw, far more portable than a 14" (355mm) chop saw.

  • Multi-Material cutting technology. One saw, one blade, cuts all.*
  • Accurate cutting - cuts mild steel with ready-to-weld, clean & square cold-cuts.
  • Unlike abrasive cutting, the RAGE4 TCT blade cuts steel with no harmful dust, no burrs & virtually no sparks, leaving an instantly workable finish.
  • Reliable smooth square cutting every time in a variety of materials.
  • Powerful 1250W hi-torque motor with optimized gearbox & blade system.
  • Accurate & durable vice portability with 0˚ - 45˚ miter detents.
  • A robust, durable base - ideal when handling heavy-duty, metallic applications.
  • Lightweight, easy to transport, taking up little space, weighing only 20.1 lbs (9.1kg).
  • Versatile, repositional fence for cutting of round, square & rectangle materials.
  • Chip guard & dust extraction port for added safety & cleaner working environment.
  • Compatible with the Evolution 7-1/4" (185mm) Diamond blade for cutting stone, concrete, and brick. (Sold separately).
  • Premium Japanese Tungsten-Carbide-Tipped (TCT) 7-1/4" blade included.
  • 3 Year limited warranty.
Cutting Capacity
Max. Cross Cut (0° x 0°): 1-3/4 in. x 3-3/4 in.
Max. Miter Cut (45° x 0°): 1-5/8 in. x 1-5/8 in.
Max Round Tube (0° x 0°): 2 in.
Mild Steel Plate (Max. Thickness): 1/4 in.



Cutting Applications

Wood Hardwood & tanalised decking, MDF laminates, mouldings, reclaimed wood with nails, scaffold boards & poles, stud-work.
 Ferrous Metal Mild Steel, angled, box section, square tube, metal stud dry walling, rebar, RSJs, plate (1/4 inch), unistrut.
 Non-Ferrous Metal Aluminum, armoured cables, cable tray, copper, floor edgings, roof flashings, stair nosings.
 Plastic Electrical conduit, plastic pipes, plexiglas, rubber & reinforced hoses, (WPC) Wood Plastic Composites.
 Not Recommended Hardened high carbon, coated and stainless steel.
Note: Cutting galvanised steel may reduce blade life.



Specifications

Machine

 Motor (120V 60Hz): 10A
Speed No Load: 4200rpm
Max. Miter: 45°


Blade

Blade Dia.: 7-1/4 in.
No. of Teeth:
20
Bore:
20 mm
Kerf: 0.066 in.


Dimensions

Product Dimensions: 10 x 15 x 10.5 In.
Packaging Dimensions:
20-5/64 x 12-19/32 x 12-13/64 in.
Product Weight:
20.1 lbs
Packaged Weight:
22.4 lbs



Items Included

Instruction Manual
20T Multi-Material TCT Blade
15/65 in. Hex Key (Vice Adjustment)
1/8 in. Hex Key (Upper Blade Guard)
13/64 in. Hex Key (Blade Change)
Rubber Vice Jaw Protector
Dust Extraction Port
Spare Motor Brushes



Documents

Download PDF Manual Spare Parts (Head)
Spare Parts (Base)
Guarantee

Please Note: We are unable to ship to or service product warranty claims in: Puerto Rico, Guam, U.S. Virgin Islands, Northern Mariana Islands, American Samoa, and the United States Minor Outlying Islands.

Summary Of Cover:

• All Evolution saws and drills are covered with 3 years guarantee.
• (This guarantee does not cover blades & accessories, incl. circular saw tracks).
• Evolution chop saw stand has 2 years guarantee.
• Refurbished models are covered with a 1 year guarantee.
• Please keep your proof of purchase.
• Your guarantee becomes effective at the date of delivery.
• You must provide proof of delivery / purchase before any work can be carried out on your machine. Without this proof, any work carried out will be chargeable.
• All work will be carried out by Evolution, in Davenport Iowa.
• Any parts which are replaced will become the property of Evolution.
• The repair or replacement of your machine under warranty will not extend the period of warranty.
• Evolution Power Tools reserves the right to optionally repair or replace it with the same or equivalent item.
• This guarantee statement provides benefits which are additional to and do not affect your statutory rights as a consumer.

For more info go to our warranty page.

If you are not completely satisfied with the performance of your product, simply contact our freindly Evolution customer care team, based in Davenport Iowa. Open Monday - Friday 8:30am to 5pm). You can call us on (866) EVO-TOOL / 866-386-8665.

To speed up the process, remember to have your receipt, invoice or order reference number plus your product’s serial number found on the product’s motor label.
