Evolution R185CCS: Multi-Material Cutting Circular Saw 7-1/4 in. Blade

$109.00

Buy Now

×

Evolution R185CCS: Multi-Material Cutting Circular Saw 7-1/4 in. Blade

SKU: R185CCS

Multi-Material cutting technology.
Adjustable 2-1/2 inch depth of cut.
0° - 60° bevel tilt with 22.5° and 45° bevel detents.
Powerful 15A motor, Hi-torque gearbox.

Frequently Bought Together

Compatible with:

Description

The ideal circular saw for any trade or workshop. Featuring adjustable 2-1/2 inch cutting depth and 0˚ - 60˚ bevel tilt with 22.5° and 45° bevel detents. This saw has the power to perform - tested and trade rated to cut through a variety of materials with ease.

Multi-Material cutting technology. One saw, one blade, cuts all.*
Accurate cutting with adjustable 2-1/2 inch depth of cut - perfect for trench cutting.
Reliable, smooth square cutting every time in a variety of materials.
Powerful 15A hi-torque motor with an optimized gearbox and blade system.
0° - 60° bevel tilt with 22.5° and 45° bevel detents cuts angles accurately and easily.
LED Light channeled airflow and base indicators ensure optimum visibility of your cutting line.
Ergonomic, soft-grip handles provide maximum control, versatility, and precision.
Dust extraction port and adaptor included for vacuum compatibility.
Japanese Tungsten-Carbide-Tipped (TCT) 7-1/4 inch blade included.
3 Year limited warranty.

Cutting Capacities

Max. Depth of Cut (0°):	2-1/2in.
Max. Depth of Cut (45°):	1-9/16in.
Max. Depth of Cut (60°):	1in.
Mild Steel Plate (Max. Thickness):	1/4in.
Mild Steel Box Section (Max. Wall Thickness):	1/4in.

Cutting Applications

Wood	Hardwood & tanalised decking, MDF laminates, mouldings, reclaimed wood with nails, scaffold boards & poles, stud-work.
Ferrous Metal	Mild Steel, angled, box section, square tube, metal stud dry walling, rebar, RSJs, plate (1/4 inch), unistrut.
Non-Ferrous Metal	Aluminum, armoured cables, cable tray, copper, floor edgings, roof flashings, stair nosings.
Plastic	Electrical conduit, plastic pipes, plexiglas, rubber & reinforced hoses, (WPC) Wood Plastic Composites.
Not Recommended	Hardened high carbon, coated and stainless steel. Note: Cutting galvanised steel may reduce blade life.

Specifications

Machine

Motor (120V 60Hz):	15 A
Speed No Load:	3700 rpm
Max. Bevel (Left):	60°
Circular Saw Base:	Cast Aluminum
Cable Length:	13ft

Blade

Blade Dia.:	7-1/4"
No. of Teeth:	16 & 20
Arbor:	25/32 in.
Kerf:	0.066 in.

Dimensions & Weights

Product Dimensions:	10 x 15 x 10.5 In.
Packaging Dimensions:	14.5 x 11 x 9 In.
Product Weight:	10.8 lbs
Packaged Weight:	13.2 lbs

Items Included

16T Multi-Material TCT Blade

Hex Key (Blade Change)

Parallel Edge Guide

Dust Port Adapter

Dust Hose Connector

LED Light
